PQ001-SFC- Solid Fat Content Analyzer Benchtop NMR

The PQ001-SFC NMR Analyzer was launched in 2008. After years of upgrade, PQ001 has many advantages such as small size, high precision, good repeatability, good stability and excellent cost/benefit performance. PQ001 has been widely used in the determination of Solid Fat Content.

Basic Parameters:
Magnet: permanent magnet 0.5±0.08T
Probe:Ø10mm
Effective sample detection area:Ø10mm×H10mm;
Size (L, W, H): 1685mm×520mm×386mm
Weight: 134Kg

Functions:
Determination of solid fat content;

Features:
Test accuracy: 0.1% error for 5% oil content; 0.02% error for 0.5% oil content;
Repeatability: Relative standard deviation less than 2%;
Test limitation: 10mg oil or water;
Compliance with national standards: ISO8292 AOCS Cd 16b-93;
User friendly Win7 operation system and easy-to-use software; operating personnel can operate easily even with no training; multi-language.
